Output Name Description Units
AO4 FAN SPEED Fan Speed 0_100%
BO1 DAMPER CW Damper Clockwise
BO2 DAMPER CCW Damper Counter Clockwise
BO5 FAN Fan
BO6 HT STAGE 1 Heating Stage 1
BO7 HT STAGE 2 Heating Stage 2
BO8 HT STAGE 3 Heating Stage3
Output objects (continued)
Value objects
BACnet value objects represent setpoints or other operational conditions in
the controller.
Note: Not all objects are present in every model.
Object Name Description
AV1 SPACE TEMP Space Temperature
AV2 STPT REFERENCE Setpoint Reference
AV3 ACT COOL STPT Active Cooling Setpoint
AV4 ACT HEAT STPT Active Heating Setpoint
AV5 OCC CL STPT Occupied Cooling Setpoint
AV6 OCC HT SPT Occupied Heating Setpoint
AV7 UNOCC CL STPT Unoccupied Cooling Setpoint
AV8 UNOCC HT STPT Unoccupied Heating Setpoint
AV9 MIN CL STPT Minimum Cooling Setpoint
AV10 MAX HT STPT Maximum Heating Setpoint
AV11 MIN STPT DIFF Minimum Setpoint Differential
AV12 STBY DIFF Standby Differential
AV13 MIN COOL FLOW Minimum Cooling Flow
Table 8–4 Analog value objects
Section 8: System integration and networking SimplyVAV
78 Revision E
