Procedure Steps STE display
7 Measure and enter the
actual minimum
secondary airflow The display begins flashing SMIN and also
displays the actual airflow at the bottom.
Note: The airflow displayed by the STE-8000
in this step is the actual, uncorrected airflow.
1. Wait for the minimum airflow value to
stabilize.
2. With a flow hood, measure the actual airflow.
3. Press the Set Point
button to advance to the entry
display. SMIN stops flashing.
4. Press the or buttons to enter the
measured airflow.
5. Press the Set
Point
button to save the measured
airflow. The display advances to SEC .
SMIN
OO
8 Advance or exit 1. Press the or buttons to select one of the
following:
PRI to balance the primary VAV for dual
duct systems
BACK to choose another configuration
function.
EXIT to return to the temperature display.
2. Press the Set
Point
button to select the next function.
SEC
The airflow balancing procedure (continued)
SimplyVAV Section 5: Balancing airflow
