HTO-1103 FlexStat Firmware Flash Upgrade Kit

1

Installation Guide, Rev. N

Installation Guide

FlexStat Firmware Upgrade (and CO

2

Calibration Adapter) Kit

HTO-1103

Kit Identification 1

HTO-1103 (formerly KMD-5699)

1

HTO-1104 1

Software and Firmware Installation 2
Connections 3
Updating the Firmware 5
Troubleshooting 6
Updating Nonreleased Firmware

7

Tips and Additional Information

7

Downloading New Firmware Versions 7
Deleting Old Firmware Versions

7

Custom Control Basic Issues

8

CO

2

Calibration Adapters 8

Important Notices 8

Kit Identification

HTO-1103 (formerly KMD-5699)

If you have a kit containing a BLUE integrated

programming pod and connector that plugs

directly into the back of the FlexStat (with a

pin extender for CO

2

model FlexStats), use the

instructions in THIS document to upgrade the

firmware in your FlexStat.

HTO-1104

If you have a kit containing a BLACK

“universal” programming pod with a

ribbon cable (and pin extender) that

plugs into the back of the FlexStat, see

the connection information in the

Firmware Upgrade Tool

instructions (905-019-

03). The HTO-1104 kit

also has several other

narrower ribbon cables

for other types of KMC

controllers.

NOTE: Orientation of

the flash port

connection

in either kit

depends on the

FlexStat model.

See

Illustration

6 on page 4

.

NOTE: Both kits also

include multiple

FlexStat backplates

(see

Illustration 6

on page 4

) and

a CO

2

calibration

tube adapter (see

Illustration 14 on

page 8

).

NOTE: The KMD-5699 part

number was changed

to HTO-1103 in Aug.

2010.
