Configuring the VAV
Box options
The box options set the controller for the specific mechanical installation of
the VAV terminal unit. The box options include the following items.
The K-factor for the VAV terminal unit. If the K-factor is not available,
see the topic
.
Reheat configuration (optional)
Fan configuration (optional)
Direction of damper to close
Setting the box options requires entering Password 2 which is described in
the topic
Getting started with configuration
Tip:
Once the following procedure is started, all steps must be completed in
order.
Procedure
Detailed steps
STE display
1
Starting display
1.
Start at the temperature display.
2.
Press the
and
buttons together.
l
If Password 2 is not required, the display
changes to
CNFG
.
l
If required, enter Password 2. The display
changes to
CNFG
when Password 2 is
correct.
3
237
////
2
Select the box settings
display.
1.
From the
CNFG
display, press the
or
buttons to show the
BOX
display.
2.
Press the
Set
Point
button to select the
CNFG
options.
The display changes to
STPT
.
3.
Press the
or
buttons to change the
display to
BOX
.
4.
Press the
Set
Point
button to select
BOX
.
CNFG
STPT
BOX
Procedure to set the box functions
SimplyVAV
Section 4: Configuring the controllers
Revision E
31
