Specifications SimplyVAV specifications are subject to change without notice.
Inputs and outputs
All inputs and outputs are factory programmed and application specific. No
field configuration is required. For details on input and output connections,
see the topic
Application drawings on page 49 . For a detailed listing of input
and output objects, see the topic BACnet objects on page 77 .
Analog inputs
Analog inputs represent BACnet analog input. Not all input are
applicable or required for all models.
Key features Standard units of measure.
Overvoltage input protection
Connectors RJ-45 room sensor jack
Screw terminals for wire sizes 12-26 AWG
Conversion 12–bit analog–to–digital conversion
Input range Passive, 10 kΩ pull-up to 3.3 volts DC
Analog outputs
Analog outputs are configured to represent BACnet analog output
objects. No field configuration is required. For details on application
specific output connections see the section
Application drawings on page
49 .
Key features Output short protection
Standard units of measure
Connector Screw terminals for wire size 12-26 AWG
Conversion 12–bit digital-to-analog conversion
Output voltage 0–10 VDC
Output current 30 mA per output, 30 mA total for all analog
outputs
Binary outputs
Binary outputs are configured to represent BACnet binary output
objects. No field configuration is required. For details on application
specific output connections see the section
Application drawings on page
49 .
Key features Optically isolated triac output
