BACnet objects The SimplyVAV controllers are BACnet Application Specific Controller (ASC)
that are composed of standard BACnet objects. This section lists the objects
that are likely to be monitored by a standard BACnet operator workstation
to verify system operation.
Caution
Changing the configuration of any object may result in
unpredictable operation of a controller and damage to
equipment that is under control of a SimplyVAV controller.
Input objects
The following BACnet input objects represent values at the physical inputs of
the controller. For wiring details, see the topic
Application drawings on page
49 .
Input Name Description Object type
AI1 DISCHARGE AIR Discharge Air Temperature KMC10K_Type_III
AI2 SPACE SENSOR Space Sensor KMC Type II Deg F
AI3 SPACE
SETPOINT Space Setpoint TABLE_4
AI4 PRIMARY DUCT Primary Duct Pressure
AI5 SECONDARY
DUCT Secondary Duct Pressure
Table 8–2 Input objects
Output objects
The following BACnet output objects represent values at the physical outputs
of the controller. For application specific output wiring details, see the topic
Application drawings on page 49 .
Output Name Description Units
AO3 ANALOG HEAT Analog Heat 0_100%
Table 8–3 Output objects
