Page 33
Procedure
Detailed steps
STE display
6
Set the fan option.
Not used in all models.
1.
Press the
or
buttons to choose one of the
following fan options.
None
—No fan is connected to the controller.
Series
—The VAV unit includes a series fan.
Parallel
—The VAV unit includes a parallel fan.
2.
Press the
Set
Point
button to save the fan option and
advance to the next function.
NONE
FAN
7
Set the damper direction
to close.
1.
Press the
or
buttons to which direction
to damper moves to close.
CCW
—The actuator turns counterclockwise to
close the damper.
CW
—The actuator turns clockwise to close the
damper.
2.
Press the
Set
Point
button to save the damper option
and advance to the next function.
CCW
DDIR
8
Select a new
configuration function or
exit.
1.
Press the
or
buttons to select one of the
following:
STPT
,
FLOW
,
ADVC
. or
RSTR
options
BACK
to choose another configuration
function
EXIT
to return to the temperature display.
2.
Press the
Set
Point
button to select the next function.
BOX
Procedure to set the box functions (continued)
SimplyVAV
Section 4: Configuring the controllers
Revision E
33
