Setting up network
communications
Set the network communication settings before placing a controller on the
network. Setting network settings requires entering Password 2 which is
described in the topic
Getting started with configuration
.
Procedure
Detailed steps
STE display
1
Starting display
1.
Start at the temperature display.
2.
Press the
and
buttons together.
l
If Password 2 is not required, the display
changes to
CNFG
.
l
If required, enter Password 2. The display
changes to
CNFG
when Password 2 is
correct.
3
237
////
2
Select the
CNFG
display
1.
From the
CNFG
display, press the
or
buttons to advance to the
COMM
display.
2.
Press the
Set
Point
button. The display changes to
DID
.
CNFG
COMM
3
Enter the device instance.
1.
Press the
or
buttons to change the first
digit.
2.
Press the
Set
Point
button to select the next digit.
Repeat for all seven digits.
3.
When the
Set
Point
button is pressed for the last
digit, the display changes to
MAC
.
D ID
OO72O69
4
Enter the MAC address.
1.
Press the
or
buttons to change the MAC
address.
2.
Press the
Set
Point
button to save the selected MAC
address.
The display changes to
BAUD
.
MAC
11
Table 8–1
Procedure to set up network communications
