98 Publication 1404-UM001F-EN-P - November 2009
Chapter 4 Communication
Please contact Rockwell Automation technical support if you find that
the default settings do not result in adequate network performance.
Explicit Messaging
Use explicit messaging to read and write all data tables other than the
I/O messaging table. The specific details of explicit messaging depend
upon the master device that initiates the message. The example in this
section uses an Allen-Bradley SLC 500 controller and DeviceNet
Scanner (1747-SDN) as the master.
Refer to the DeviceNet Scanner Module Installation Instructions,
publication 1747-IN058, for a detailed description of explicit message
programming in the SLC 500 controller.
Please refer to the Rockwell Automation KnowledgeBase for other
examples of explicit messaging to a Powermonitor 3000 unit.
In the SLC 500 and PLC-5 controllers, you assemble the explicit
message header in an integer file and transfer it to the scanner
module. When the response is received, you transfer the response
from the scanner to another integer file. The message header consists
of 6 words organized as follows.
Explicit Messaging
Message Word High byte Low byte
Header 0 Transmit ID Command
1 Port Size
2 Service MAC ID
Body 3 Class
4 Instance
5 Attribute
6 Data to write if applicable
7
. . .
n
