Publication 1404-UM001F-EN-P - November 2009 267
Powermonitor 3000 Data Tables Appendix A
Single Parameter Read Parameters
CSP File No. -
Remote I/O BT -
CIP Assy. Inst. 80…102
No. of Elements 1 each
User Configurable No
Data Type Floating point, little-endian, fixed configuration, or integer (see listing)
Data Access Read only
PM3000 Type DeviceNet units only
Single Parameter Read
CIP Assy.
Instance Parameter Name Data Type Range Comment
80 Ave L-L Volts Float
0.0…999.9x10
21
81 L1-L2 Volts Float
0.0…999.9x10
21
82 L2-L3 Volts Float
0.0…999.9x10
21
83 L3-L1 Volts Float
0.0…999.9x10
21
84 L1 Amps Float
0.0…999.9x10
21
85 L2 Amps Float
0.0…999.9x10
21
86 L3 Amps Float
0.0…999.9x10
21
87 L4 Amps Float
0.0…999.9x10
21
88 Demand Power Float
0.0…999.9x10
21
89 Demand VARs Float
0.0…999.9x10
21
90 3 Ph PF Float
0.0…999.9x10
21
91 Ave Amps Float
0.0…999.9x10
21
92 Ave L-N Volts Float
0.0…999.9x10
21
93 Frequency Float 0, 40 … 75, 999
94 Total Watts Float
0.0…999.9x10
21
95 Total VARs Float
0.0…999.9x10
21
96 Total VA Float
0.0…999.9x10
21
97 Energy kWh x 1 Integer 0…999
98 Energy kWh x 1,000 Integer 0…999
99 Energy kWh x 1,000,000 Integer 0…999
100 Energy kVARh x 1 Integer 0…999
101 Energy kVARh x 1,000 Integer 0…999
102 Energy kVARh x 1,000,000 Integer 0…999
