152 Publication 1404-UM001F-EN-P - November 2009
Chapter 7 Data Logging
The power monitor clears the trend log when you change any
parameter or the logging interval.
You may perform a simple table read of the Trend Log
Configuration/Read-back Record Select table to view the existing
Trend Log configuration.
When you read this table, the password element returns a value of -1
and the reserved and command elements return a value of 0. Elements
7 and 8 return the Total Records Logged * 1000 and * 1 respectively.
Reading Data from the Trend Log
To read the Trend Log, use the indexed read method.
A write to the Trend Log Configuration/Read-back Record Select table
selects which trend log record is read next.
There are a number of auto-increment and manual-increment options
that may be selected by writing to the Read-back Mode element in the
Trend Log Configuration/Read-back Record Select Parameters table.
You can select from the following options:
0 - Auto-increment / start at beginning: Start at the oldest log
record and index to the next record after each read of the results
table
1 - Auto-increment / start at end: Start at the newest log record
and index to the next record after each read
2 - Auto-decrement / start at end: Start at the newest log record
and index to the previous record after each read
3 - Point to the oldest log record
4 - Point to the newest log record
5 - Index to the next record after each read of the results table
6 - Index to the previous record after each read
TIP
Although you may configure up to 16 Trend Log parameters on units
with optional DeviceNet communication, the results table will return
only the first 8.
