Setpoint types – Rockwell Automation 1404-M4_M5_M6_M8 Powermonitor 3000 User Manual, Firmware rev. 3.0 or LATER User Manual
Page 129
Publication 1404-UM001F-EN-P - November 2009
129
Setpoint Programming and Operation Chapter 5
Setpoint Low Limit
The value being used as a reference to
deactivate the setpoint for over comparisons,
or to activate the setpoint for under
comparisons.
0…10,000,000
Depends on type
0
Setpoint Action Delay The minimum time in seconds that the
setpoint limit must be exceeded continuously
before the setpoint will trigger.
0…3600
Sec (M4, M5)
0
0…30,000
0.1 Sec (M6, M8)
Setpoint Release
Delay
The minimum time in seconds that the
setpoint limit must not be exceeded
continuously before the setpoint releases.
0…3600
Sec (M4, M5)
0
0…30,000
0.1 Sec (M6, M8)
Setpoint Action Type
The action that occurs when the setpoint is
triggered.
0…32 (see details in the
Setpoint Action Type table on
0
Clear Accumulated
Time
Clear the time accumulator for this setpoint
Yes
No
N/A
Setpoint Configuration
Parameter Name
Parameter Description
Range
Units
Default
Setpoint Types
Setpoint Type
Description
Units
M4,
M5
M6
M8
0
Not used
-
•
•
•
1
Voltage
(1)
Volts
•
•
•
2
Current
(1)
Amps
•
•
•
3
Voltage unbalance
Percent
•
•
•
4
Current unbalance
•
•
•
5
Neutral current
Amps
•
•
•
6
W
Watts
•
•
•
7
VAR
VARs
•
•
•
8
VA
VA
•
•
•
9
Total true PF
Percent
•
•
•
10
Total disp PF
•
•
•
11
Total dist PF
•
•
•
12
W demand
Watts
•
•
•
13
VAR demand
VARs
•
•
•
14
VA demand
VA
•
•
•
15
Amp demand
Amps
•
•
•
16
Projected amp demand
Amps
•
•
•
17
Projected W Demand
Watts
•
•
•
18
Projected VAR Demand
VARs
•
•
•
19
Projected VA Demand
VA
•
•
•
20
Frequency
Hz
•
•
•
21
Phase rotation
-
•
•
•
22
Crest factor voltage
Volts
•
•
•
23
Crest factor current
Amps
•
•
•
