Appendix A Powermonitor 3000 Data Tables
TIP
Data appears in the first two words of the input image table
corresponding to the Powermonitor 3000 logical rack. For example,
with the unit configured as Rack 1, Group 1 in a 1747-SN scanner
residing in Slot 2, the data will appear in words I:2.8 and I:2.9 of the
data table.
Remote I/O Discrete Data Accepted by Powermonitor Units (Master Output Data)
Element
No.
Element name
Range
Comment
1
Relay control
0 or 128
0 (Bit 8 = 0): De-energize
128 (Bit 8 = 1): Energize
Must be enabled by Control source parameter
2
KYZ control
DeviceNet, EtherNet/IP, and ControlNet I/O Data Provided by Powermonitor Units (Scanner Input Data; Instance 1)
Element
No.
Element name
Range
Comment
0
Relay output status
0…3
0 = De-energized & not forced
1 = Energized & not forced
2 = Forced de-energized
3 = Forced energized
1
Solid-state KYZ output status
2
Alarm output word
0…FFFF
Bitfield indicates state of 16 alarm output flags; 0 = released, 1 = asserted
Bit 0 = relay/setpoint output flag 1
Bit 1 = KYZ/setpoint output flag 2
Bit 2 = setpoint output flag 3
…
Bit 15 = setpoint output flag 16
3
Status inputs state
0…7
Bit 0 = status input 1; 0 = open, 1 = contact closure detected
Bit 1 = status input 2; 0 = open, 1 = contact closure detected
Bit 2 = demand sync timeout; 1 = the demand delay expired before the next
expected external demand sync. This bit clears when the next external
demand sync occurs.
Refer to Advanced Device Configuration Parameters
element 23.
Bits 3…15 = unused (always 0)
4
Status input #1 counter
0…
29,999
Counts to 29,999, rolls over to 0.
5
Status input #2 counter
TIP
Size and content of Instance 1 may vary depending on user
configuration.
Refer to User-configured Data Table on page 121
more information.
DeviceNet, EtherNet/IP, and ControlNet I/O Data Accepted by Powermonitor Units (Scanner Output Data; Instance 2)
Element
No.
Element name
Range
Default
Value
Comment
0
Relay output
0…1
-
0 (Bit 8 = 0): De-energize
256 (Bit 8 = 1): Energize
Must be enabled by Control source parameter
1
Solid-state KYZ output
0…1
