212 Publication 1404-UM001F-EN-P - November 2009
Appendix A Powermonitor 3000 Data Tables
Selftest/Diagnostic Results Parameters
CSP File No. N22
Remote I/O BT 36
CIP Assy. Inst. 23
No. of Elements 27
User Configurable No
Data Type Integer
Data Access Read only
PM3000 Type All
Selftest/Diagnostic Results
Element
No. Modbus
Address Element name Range Comment
0 30601 Bulletin number 1404
1 30602 Series 0…8 0 = A, 1 = B
2 30603 Overall status - 0 = OK
3 30604 Data Acquisition status - 0 = OK
bit 0 = overall status; 0 = pass, 1 = fail
bit 1 = reserved
bit 2 = data bus connection failure
bit 3 = address test failure
4 30605 Data FLASH status - 0 = OK
5 30606 Real-time clock status - 0 = OK
6 30607 RTC NVRAM status - 0 = OK
Non-zero indicates corruption of nonvolatile memory. This does
not cause product to shutdown. The error is cleared on a
reset/power cycle. If this error is detected, date/time, and
energy values are reset.
7 30608 Option communication status - 0 = OK or no optional communication present
8 30609 Display module status - 0 = OK or no DM connected
9 30610 Watchdog status - 0 = OK
10 30611 Code FLASH status - 0 = OK
bit 0 = overall status; 0 = pass, 1 = fail
bit 1 = boot code checksum failure
bit 2 = application code checksum failure
bit 3 = calibration CRC failure
bit 4 = no calibration data
bit 5 = wrong application firmware loaded
11 30612 RAM status - 0 = OK
bit 0 = read/write test failure
12 30613 Application FRN 0…9999 100 indicates version 1.00, 103 indicates version 1.03…
13 30614 Boot code FRN 0…9999 100 indicates version 1.00, 101 indicates version 1.01…
