Rockwell Automation 1404-M4_M5_M6_M8 Powermonitor 3000 User Manual, Firmware rev. 3.0 or LATER - Manual (Page 338)

338 Publication 1404-UM001F-EN-P - November 2009
Appendix D Technical Specifications
General Input, Output, and Environmental Ratings
Input and Output Ratings
Control Power 1404-xxxxA-xxx 102…264V ac 47…63 Hz or
106…275V dc
(0.2 A max loading)
1404-xxxxB-xxx 18…50V dc (15V A max loading)
Voltage Sense
Inputs: V1, V2, V3 Input Impedance: 1 Mohm min, 399V ac max; V1, V2 and V3 to N.
Current Sense
Inputs: I1, I2, I3, I4 Overload Withstand:
15 A Continuous,
200 A for 1 s
Burden: 0.05V A
Impedance: 0.002 ohms
Maximum Crest Factor at 5 A is 3
Starting Current: 5 mA
Status Inputs Contact Closure (Internal 24V dc)
Control Relay
KYZ Output (1) ANSI C37.90-1989 trip duty
(1) Solid State KYZ - 80 mA at 240…300V dc
Control Relay
(1)
(1) Meets ANSI/IEEE C37.90-1989 standards for trip duty.
Rating 50/60 Hz ac rms DC
Max Resistive Load Switching 10 A at 250V
(2500V A) 10A at 30V and 0.25A at
250V
Min Load Switching 10 mA at 24V 10 mA at 24V
UL 508, CSA 22.2, IEC Rating
Class B300 Q300
Max Make Values (Inductive
Load) 30 A at 120V
15 A at 240V
(3600V A) 0.55 A at 125V
0.27 A at 250V
(69V A)
Max Break Values (Inductive
Load) 3 A at 120V
1.5 A at 240V
(360V A) 0.55A at 125V
0.27 A at 250V
(69V A)
Max Motor Load Switching 1/3 HP at 125V
1/2 HP at 250V
Relay Life
(1)
(1) Meets ANSI/IEEE C37.90-1989 standards for trip duty.
Parameter Number of Operations
Mechanical
5 X 10
6
Electrical
1 X 10
5
