Page 231
Publication 1404-UM001F-EN-P - November 2009
231
Powermonitor 3000 Data Tables Appendix A
List of Event Types Parameters
Applies to
Event Log Results Parameters on
PM3000 Type
See table
List of Event Types
Event
Code.
M4
M5
M
6
M
8
Event Type
Event Command
Code
Comment
0
•
• •
No event
0
The log starts with no events recorded
1
•
• •
Setpoint triggered
Setpoint Number
A setpoint activated
2
•
• •
Setpoint released
A previously active setpoint released
3
•
• •
Relay force energized
Relay Number
1 = Form C relay, 2 = KYZ
4
•
• •
Relay force de-energized
5
•
• •
Relay force released
6
•
• •
Status input set
Status Input Number
7
•
• •
Status input cleared
8
•
• •
kWh counter set or cleared
1
Records command action
8
•
• •
kVARh counter set or cleared
2
8
•
• •
kVAh counter set or cleared
3
8
•
• •
Ah counter set or cleared
4
8
•
• •
All energy counters cleared
5
8
•
• •
Trend log cleared
6
8
•
• •
Min/max log cleared
7
8
•
• •
Factory defaults restored
8
8
•
• •
Status input #1 counter cleared
9
8
•
• •
Status input #2 counter cleared
10
8
•
• •
Reserved
11
8
•
• •
Single setpoint timer cleared
12
8
•
• •
All setpoint timers cleared
13
9
•
• •
Power-up
0
Control power was applied
10
•
• •
Power-down
0
Control power was lost or internal reset occurred
11
•
• •
Selftest failure
Status Error Code
12
•
• •
Date/time set
0
The date and/or time was set or altered
13
•
• •
Change of non-setpoint config data 0
14
•
• •
Change of setpoint config data
0
15
•
• •
NVRAM Clr
0
NVRAM has been cleared due to an extended loss
of control power or internal error
16
•
Transient detected
