Publication 1404-UM001F-EN-P - November 2009 209
Powermonitor 3000 Data Tables Appendix A
Metering Power Factor Results Parameters
CSP File No. F19
Remote I/O BT 33
CIP Assy. Inst. 18
No. of Elements 13
User Configurable No
Data Type Floating point
Data Access Read only
PM3000 Type All
Metering Power Factor Results
Element
No. Modbus
Address Element name Units Range Comment
0 30501-02 L1 True Power Factor Percent -100…100 Ratio between power and apparent power.
+ = Lead
- = Lag
1 30503-04 L2 True Power Factor -100…100
2 30505-06 L3 True Power Factor -100…100
3 30507-08 Three-phase True PF -100…100
4 30509-10 L1 Displacement Power Factor -100…100 Cosine of the phase angle between the fundamental
voltage and current.
+ = Lead
- = Lag
5 30511-12 L2 Displacement Power Factor -100…100
6 30513-14 L3 Displacement Power Factor -100…100
7 30515-16 Three-phase Displacement PF -100…100
8 30517-18 L1 Distortion Power Factor 0…100 The ratio between the magnitude of the fundamental
and the sum of the magnitudes for all of the current
harmonics.
9 30519-20 L2 Distortion Power Factor 0…100
10 30521-22 L3 Distortion Power Factor 0…100
11 30523-24 Three-phase Distortion PF 0…100
12 30525-26 Metering iteration - 0…32,767 Increments by 1…32,767, rolls over to 0.
