238 Publication 1404-UM001F-EN-P - November 2009
Appendix A Powermonitor 3000 Data Tables
Harmonic Results; THD, Crest Factor, and More Parameters
CSP File No. F34
Remote I/O BT 23
CIP Assy. Inst. 41
No. of Elements 9 (M4, M5); 10 (M6, M8)
User Configurable No
Data Type Floating Point
Data Access Read only
PM3000 Type See table
Harmonic Results; THD, Crest Factor, and More
Element
No. Modbus
Address M4
M5 M
6 M
8 Element Name Range Comment
0 31201-02
• • •
Channel number 1…9 Refer to Reading Harmonic Analysis Data on page 172
1 31203-04
• • •
% IEEE THD 0.0…1000.0
2 31205-06
• • •
% IEC thd (DIN) 0.0…1000.0
3 31207-08
• • •
Crest Factor 0.0…10.0
4 31209-10
• • •
THD & Crest iteration 0…32,767
5 31211-12
•
Reserved 0
• •
TIF
0.0…999.9x10
22
6 31213-14
•
Reserved 0
• •
K-Factor
0.0…999.9x10
22
7 31215-16
•
Reserved 0
• •
IEEE-519 TDD
0.0…999.9x10
22
8 31217-18
•
Reserved 0
• •
IEEE-519 Pass/Fail -1…1
9 31219-20
•
Reserved 0
• •
FFT iteration 0…32,767
