Chapter 2 Product Description
Performance Features
The power monitor is available in four basic models, designated M4,
M5, M6, and M8. Each model offers specific functionality as indicated
in this table. The M5 model offers M4 functionality and can be
field-upgraded to an M6 or M8 model for an additional charge.
Product Features of Powermonitor 3000 Module
M4 M5 M6 M8
Master Module Features
•
•
•
•
Voltage, current, power measurements and display
•
•
•
•
Compatible with PLC-5, SLC 500, and ControlLogix controllers
•
•
•
•
Compatible with RSLinx, RSPower, RSPowerPlus,
RSEnergyMetrix, and RSView32 software
•
•
•
•
Output control via control relays or PLC controllers
•
•
•
•
Demo mode for training
•
•
•
•
10 user configurable setpoints
•
•
•
•
Discrete condition monitoring via status inputs
•
•
•
•
Electronic KYZ pulse output
•
•
•
•
Form C ANSI C37.90-1989 rated relay for direct breaker tripping
•
•
•
•
Time stamped data logging of system measurements and events
•
•
•
•
Configurable trend log, up to 45,000 records deep
•
•
•
•
Event log 50 records deep
•
•
•
•
Firmware upgrades without removing module
•
•
•
•
Total harmonic distortion (THD) and Crest Factor
•
•
•
•
Automatic network-based time synchronization via SNTP
•
•
•
•
Daylight Saving Time
•
•
•
ANSI C12.20 Class 0.5 revenue metering accuracy
(1)
(1)
Class 0.2 revenue metering accuracy available as an extra-cost option.
•
•
•
EN60687 Class 0.5 revenue metering accuracy
(1)
•
•
•
Canadian Revenue Meter specification accuracy
•
•
Field upgradeable to M6 or M8 (extra cost option)
•
•
10 additional setpoints with more options
•
•
Event Log an additional 50 records deep
•
•
User configurable oscillography up to 400 cycles @ 60 Hz
•
•
TIF, K-factor and IEEE-519 Pass/Fail
•
•
Sag and swell detection with oscillogram capture
•
•
Load factor log 12 records (months) deep
•
•
Calculates amplitude and % distortion for harmonics 1…41
•
Calculates amplitude and % distortion for harmonics 1…63
•
Sub-cycle transient capture and metering
•
Transducer and Energy Meter modes with improved update rate
