220 Publication 1404-UM001F-EN-P - November 2009
Appendix A Powermonitor 3000 Data Tables
Trend Log Configuration/Read-back Record Select Parameters
CSP File No. N24
Remote I/O BT 34
CIP Assy. Inst. 26 (Write), 27 (Read)
No. of Elements 26
User Configurable No
Data Type Integer
Data Access Read / Write
PM3000 Type All
Trend Log Configuration/Read-back Record Select
Element
No. Modbus
Address Element Name Range Default
Value Comment
0 40801 Password 0…9999 0 Required for configuration, -1 for readback select, returns -1
1 40802 DeviceNet unique write
identifier -32,768…
32,767 0 Refer to DeviceNet Unique Write Identifier on page 103
2 40803 Reserved 0 0 Must be 0 on a write; returns 0
3 40804 Read-back mode 0…6 2 Refer to Setting up the Trend Log on page 151 , and Reading
Data from the Trend Log on page 152
4 40805 Logging interval -1…3600 900
(15 min) Expressed in seconds
-1 = synchronize logging with demand interval
0 = disable periodic logging
5 40806 Logging mode 0…1 0 0 = Overwrite
1 = Fill and hold
6 40807 Clear trend log command 0…1 0 0 = no action
1 = clear trend log; returns 0
7 40808 Total records logged x 1000 0…999 - Number of records = element 7 x 1000 + element 8
8 40809 Total records logged x 1 0…999 -
9 40810 Reserved 0 - Must be 0 on a write; returns 0
10 40811 Parameter #1 selection 1…301 122 Refer to Setting up the Trend Log on page 151
Defaults:
Parameter 1: 122, Net Kilowatt-hours
Parameter 2: 126, Net kVAR-hours
Parameter 3: 100, Demand watts
11 40812 Parameter #2 selection 0…301 126
12 40813 Parameter #3 selection 100
13 40814 Parameter #4 selection 0
14 40815 Parameter #5 selection
15 40816 Parameter #6 selection
16 40817 Parameter #7 selection
17 40818 Parameter #8 selection
