Chapter 8 Advanced Features
Configuring Oscillography
You may configure oscillography only via communication. The
display module does not support an interface to oscillography.
Configure oscillography by performing a table write to the
Oscillograph Configuration/Read-back Data Select
table of 11 integer elements comprises the following configuration
and command parameters.
•
Password: needed to configure the capture type or pre-trigger,
or execute a command to trigger or clear a capture. Not needed
for read-back select, use -1. Default 0000.
•
Capture number: selects a capture for read-back or returns the
last capture selected. Range 1…8 (M6) or 1…2 (M8). Default 1.
•
Channel number: selects a channel number or returns the last
channel number selected. Range: 1 = V1, 2 = I1, 3 = V2, 4 = I2, 5
= V3, 6 = I3, 7 = I4. Default 1.
•
Block number: selects a data block for the next read or returns
the last block selected. Range depends on communication type.
See below. Default 1.
•
Read-back mode: selects a read-back mode or returns the last
mode selected. Range 0…2, default 0. See below.
•
Clear / trigger command: clears one or all captures or triggers a
new capture. Always returns 0. In the M8 model, values of 3…8
have same meaning as 0. These are the options:
0 - no action
1 - clear capture 1
2 - clear capture 2
3 - clear capture 3 (M6 only)
4 - clear capture 4 (M6 only)
5 - clear capture 5 (M6 only)
6 - clear capture 6 (M6 only)
7 - clear capture 7 (M6 only)
8 - clear capture 8 (M6 only)
9 - clear all captures
10 - initiate a new capture
•
Capture type: selects sample rate and data resolution or indicates
selected sample rate and resolution. Range -1…5, default 0. -1
disables oscillography.
See the Capture Type Properties table on
•
Pre-trigger: specifies how much of the captured waveform
occurred before the triggering event. Range 0…100 per cent,
default 90%.
•
Reserved: must be zero (0) on a write, returns 0.
