Publication 1404-UM001F-EN-P - November 2009 237
Powermonitor 3000 Data Tables Appendix A
Harmonic Analysis Configuration/Read-back Select Parameters
CSP File No. N33
Remote I/O BT 14
CIP Assy. Inst. 39 (Write), 40 (Read)
No. of Elements 9
User Configurable No
Data Type Integer
Data Access Read /Write
PM3000 Type See table
Applies to: Harmonic Results; THD, Crest Factor, and More Parameters on page 238 (All models)
Harmonic Results; Odd Harmonics 1…21 Parameters on page 239 ,Harmonic Results;
Odd Harmonics 23…41 Parameters on page 240 , Harmonic Results; Even Harmonics
2…20 Parameters on page 241 , Harmonic Results; Even Harmonics 22…40
Parameters on page 242 (M6 & M8)
Harmonic Results; Odd Harmonics 43…63 Parameters on page 256 , Harmonic Results;
Even Harmonics 42…62 Parameters on page 257 (M8 only)
Harmonic Analysis Configuration/Read-back Select
Element
No. Modbus
Address M4
M5 M
6 M
8 Element Name Range Default
Value Comment
0 41201
• • •
Password 0…9999 0 Required for configuration, -1 for readback
select, returns -1.
1 41202
• • •
Channel 1…9 1 Refer to Configuring Harmonic Analysis on
page 171
.
2 41203
• • •
Read-back mode 0…1 0
3 41204
•
Reserved 0 0
• •
Individual harmonic data type 0…1 0
4 41205
•
Reserved 0 0
• •
Enable/disable Harmonics 0…1 1
5 41206
•
Reserved 0 0
• •
IEEE-519 Max I
sc
Integer 0…9999 0
6 41207
•
Reserved 0 0
• •
IEEE-519 Max I
sc
Exponent -4…21 0
7 41208
•
Reserved 0 0
• •
IEEE 519 Max I
dmnd
Integer 0…9999 0
8 41209
•
Reserved 0 0
• •
IEEE 519 Max I
dmnd
Exponent -4…21 0
