Publication 1404-UM001F-EN-P - November 2009 199
Powermonitor 3000 Data Tables Appendix A
Optional Communication Configuration Parameters
CSP File No. N14
Remote I/O BT 24
CIP Assy. Inst. 12 (Write), 13 (Read)
No. of Elements 20
User Configurable No
Data Type Integer
Data Access Read / Write
PM3000 Type All
TIP
Select the table that applies to your Powermontior 3000 unit.
Ethernet
Element
No. Modbus
Address Element name Range Units Default
Value
Comment
0 40401 Password 0…9999 - 0 Valid password required to change
configuration data. Returns -1
1 40402 IP address byte a 0…255 - 192 Format: aaa.bbb.ccc.ddd. Static IP address
of this device (for example 130.151.32.86).
If connected to a network, IP address must
be unique. (255.255.255.255 is not
permitted.)
2 40403 IP address byte b 168
3 40404 IP address byte c 254
4 40405 IP address byte d Device ID Factory-assigned device ID
5 40406 Subnet mask byte a 0…255 - 255 Format aaa.bbb.ccc.ddd.
6 40407 Subnet mask byte b 255
7 40408 Subnet mask byte c 0
8 40409 Subnet mask byte d 0
9 40410 Gateway IP address byte a 0…255 - 128 IP address of the gateway on this subnet
used to route messages to other subnets
(wide area networking).
10 40411 Gateway IP address byte b 1
11 40412 Gateway IP address byte c 1
12 40413 Gateway IP address byte d 1
13 40414
Protocol selection
(1) 0…2 - 0 0 = CIP, 1 = CSP, 2 = CIP/CSP
14 40415 Reserved 0 - 0 Reserved. Must be 0 on a write, returns 0
15 40416
16 40417
17 40418
18 40419
19 40420
(1) Master module version 4 or later, Ethernet firmware version 3 or later.
