Publication 1404-UM001F-EN-P - November 2009 51
Powermonitor 3000 Unit Operations Chapter 3
Advanc
ed Configuration
New Password -1 … 9999 0000
Demand Period Length -99 … 99 15
Number of Demand Periods 1 … 15 1
Forced Demand Delay 0 … 900 s 10
Predicted Demand Type Instantaneous
1st Order
2nd Order Instantaneous
KYZ Control Source 0 = None
1 = Wh Forward
2 = Wh Reverse
3 = VARh Forward
4 = VARh Reverse 5 = Vah
6 = Ah
7 = Setpoint
8 = Comms 7 = Setpoint
KYZ Pulse Output Scale 1 … 30000 10
KYZ Pulse Output Width 0, 40 … 2000 0
Relay Control Source Same as KYZ 7 = Setpoint
Relay Pulse Output Scale 1 … 30000 10
Relay Pulse Output Width 0, 40 … 2000 100
RMS Resolution Nominal / High
High
(2)
RMS Averaging On / Off On
Frequency Averaging On / Off On
Date Format MM/DD/YYYY DD/MM/YYYY MM/DD/YYYY
Date: Year 1998 … 2097 1998
Date: Month 1 … 12 1
Date: Day 1 … 31 1
Time: Hour 0 … 23 0
Time: Minutes 0 … 59 0
Time: Seconds 0 … 59 0
Default relay state on comms loss 0 = Last state/resume
1 = Last state/freeze 2 = De-energize/resume
3 = De-energize/freeze 0
Default KYZ state on comms loss 0
Wdog action 0 = Halt
1 = Continue 0 = Halt
Display Module Scroll Speed Fast / Slow Fast
Energy counter rollover point 4 … 15 digits 15
Metering Result Set (M8 only
(1)
)
0 = All results
1 = Transducer mode
2 = Energy meter mode 0 = All results
(1) Metering result set parameter may only be configured by using communication.
(2) Factory default for RMS Resolution is Nominal for the M4 and High for the M5, M6 and M8.
Device Configurations Summary
Parameter Range Default User Setting
