Publication 1394-5.0 — May 2000

3-18

Wiring System, Axis, and Shunt Modules, and Motors (for all systems)

6. Insert one of the 24V control power wires into the terminal block

labeled W1.

7. Insert the other 24V control power wire into the terminal block

labeled W2.

8. Tighten and torque all six screw terminals to the values in the

following table.

9. Gently pull on each wire to make sure it does not come out of its

terminal. Re-insert and tighten any loose wires.

10. Go to the section Connecting Motor Power to Axis Modules.

Connecting Power Wiring for 5 and 10 kW System Modules
(Series C)

To connect power wiring:

1. Connect the system module ground wire from the system module

ground bar to the bonded ground bus bar on the subpanel. For
more information on bonding, refer to the chapter Installing Your
1394
.

2. Insert the three-phase input neutral wire into connector terminal

J10-4 and tighten the J10-4 connector screw (torque value =
0.56-0.62 N-m, 5.0-5.6 lb-in.).

Note: The three-phase input neutral connection is present only on

grounded power configurations.

3. Insert the three-phase incoming power wires as follows and

tighten the three J10 connector screws.

4. Gently pull on each wire to make sure it does not come out of its

terminal. Re-insert and tighten any loose wires.

System Module: Terminal Block

Designator:

Terminal Block
Torque:

5 and 10 kW

All

0.56 - 0.62 N-m
(5.0 - 5.6 lb-in.)

22 kW

W1, W2

0.56 - 0.62 N-m
(5.0 - 5.6 lb-in.)

DC+, COL, U, V, W, PE 2.21 - 2.66 N-m

(20.0 - 24.0 lb-in.)

Insert the wire
labeled:

Into connector
terminal:

Tighten to this
torque value:

U

J10-1

0.56-0.62 N-m
(5.0-5.6 lb-in.)

V

J10-2

W

J10-3
