Page 264
Publication 1394-5.0 — May 2000
C-2
Using the Human Interface Module (HIM)
Figure C.1
HIM Mounted on 1394 Analog Servo System
There are two SCANports located on the 1394 analog servo board.
Port 1 is located at the top of the analog servo board and port 2 is
located at the bottom of the analog servo board.
Understanding HIM Keys
The following diagram shows the HIM front panel.
Figure C.2
HIM Front Panel
1394 Digital Servo Controller
System Module
Allen-Bradley
When you are using the HIM:
Use port:
In the HIM cradle
1
As a hand-held device
2
