Publication 1394-5.0 — May 2000
D-12
Catalog Numbers
Motor Feedback Cables
Encoder Feedback Cables for 1326AB Motors
Use the following encoder feedback cables for connecting an optional
845H encoder to a 1326AB motor.
Bulletin
Number
Type
1326
Function
Motor Size
Used On
Flex Cable
Option
Connector
Accessory
IP
Rating
Cable
Length
C = Connector and cable
assembly
C = Resolver feedback
EC = High-resolution
U = Commutation and encoder cable for all series motors
T = Flex-rated cable for high-flex applications
Blank = No option, standard cable
Blank = Single-standard connector
D = Double-ended, standard connector
E = Bulkhead connector
EE = Double-ended, bulkhead connector
RA = Right-angle connector
RB = Right-angle connector
Blank = IP65
L = IP67, harsh environment
005 = 5m (16.4 ft)
015 = 15m (49.2 ft)
030 = 30m (98.4 ft)
060 = 60m (196.8 ft)
084 = 84m (275.5 ft)
090 = 90m (295.2 ft)
1
1
For use with 1326AB-B
xxxx-Mx motors only.
Bulletin
Number
Type
1326
Function
Motor Size
Used On
Cable
Length
C = Connector and cable
assembly
E = 845H encoder
U = Commutation and encoder cable for all series motors
15 = 15 ft
30 = 30 ft
50 = 50 ft
100 = 100 ft
1
1
Recommended for use with 12V encoders only.
