Publication 1394-5.0 — May 2000

Specifications

A-3

Axis Modules

The table below lists the specifications for the axis modules.

Contact Ratings

The table below lists the contact ratings of the drive relay outputs.

The:

For the 1394

x-AM03 is: For the 1394x-AM04 is: For the 1394x-AM07 is:

For the 1394

x-AM50

and 1394C-AM50-IH is:

For the 1394

x-AM75

and 1394C-AM75-IH is:

Speed Regulation

1

0 to 0.05% of base
speed with 100% torque
disturbance

0 to 0.05% of base
speed with 100% torque
disturbance

0 to 0.05% of base
speed with 100% torque
disturbance

0 to 0.05% of base speed
with 100% torque
disturbance

0 to 0.05% of base speed
with 100% torque
disturbance

Static Gain

(rms A/mV)

1

1.28

2.6

4.9

22.8

22.8

Peak Current
Limit Adjust

200%

200%

200%

143%

143%

Modulation
Frequency

5 kHz ±10%

5 kHz ±10%

5 kHz ±10%

5 kHz ±10%

5 kHz ±10%

Drift

0.03 rpm/degree C

0.03 rpm/degree C

0.03 rpm/degree C

0.03 rpm/degree C

0.03 rpm/degree C

Nominal Input
Voltage

530/680V DC

530/680V DC

530/680V DC

530/680V DC

530/680V DC

Continuous
Current (rms)

3.0A

4.5A

7.5A

23.3A

35.0A

Peak Current
(rms - 1 second)

6.0A

9.0A

15.0A

33.2A

50.0A

Continuous
Power Out 360/
460V nominal

1.6/2 kW

2.4/3 kW

4/5 kW

11.34/15.6 kW

17.8/23.8 kW

Efficiency

98%

98%

98%

98%

98%

Weight

5 kg (11.02 lb)

5 kg (11.02 lb)

5 kg (11.02 lb)

7 kg (15.44 lb) (-AM50)
6.73 kg (14.8 lb) (-AM50-IH)

7 kg (15.44 lb) (-AM75)
6.73 kg (14.8 lb) (-AM75-IH)

Capacitance

110

µ

F

110

µ

F

220

µ

F

465

µ

F

660

µ

F

1

When used with the controller in the 1394

x-SJTxx system module.

The contact rating for the: Is:

Drive OK (DROK)

115V AC/24V DC, 1A inductive

Contactor Enable Relay

115V AC/24V DC, 1A inductive

Thermal switch

115V AC/24V DC, 1A inductive
