Publication 1394-5.0 — May 2000
A-10 Specifications
Power Dissipation The power dissipation characteristics of the 1394 system and axis
modules are provided below (use for 480V or 360V input).
Important: Use the power dissipation figures shown below to
calculate cumulative system heat dissipation to ensure
that the ambient temperature inside the enclosure does
not exceed 50° C (122° F). To calculate total power
dissipation, add the dissipation of the system module to
the dissipation of the axis module(s).
System Modules
The power dissipation (in watts) of the system module types is shown
below.
Axis Modules
The power dissipation (in watts) of the axis modules is shown below:
% of Rated Power Output
Power Dissipation (in watts)
1394 x-SJT05-x 1394 x-SJT10-x 1394 x-SJT22-x
20 66 70 100
40 70 77 150
60 73 84 200
80 77 81 250
100 80 98 300
% of Rated Power
Output
Power Dissipation (in watts)
Total Inside Cabinet Outside Cabinet
AM03 AM04 AM07
AM50 1 and
AM50-IH 2
AM75 1 and
AM75-IH 2
AM50
1
AM75
1
AM50
1
AM75
1
20 24 27 33 56 85 18 18 38 67
40 30 36 48 95 145 18 18 77 127
60 36 45 63 139 212 18 18 138 194
80 42 54 78 183 279 18 18 165 261
100 48 63 93 227 346 18 18 209 324
1 The AM50/75 are designed to mount with the rear heat sink extended outside the customer-supplied enclosure. If the modules are mounted entirely inside the
customer supplied enclosure, the full power dissipation is inside the cabinet.
2
The AM50/75-IH are designed to mount entirely inside the customer-supplied enclosure.
