Page 157: Startup state, State, Status display

Publication 1394-5.0 — May 2000
Configuring Your 1394 Analog Servo System
8-21
[Shunt Ws]
Shunt short time constant weighting factor. This
parameter determines the relationship between
the short and long time constants in the thermal
model of the shunt module. The long time
constant weighting factor is 100% - Ws%.
Configure this parameter only when a custom
resistor is selected.
Active on all Smart Power 22 kW systems and 5
and 10 kW (Series C or later) systems.
Note: [Shunt Type] must be set to "custom shunt"
before making modifications to associated shunt
parameters (44-48).
Parameter Numbers
48
Parameter Group
Linear List
Display Units
%
Parameter Type
Read/Write
Change While Running
No
Minimum Value
1
Maximum Value
100
Default Value
100
[Slot 0 Opt. Card]
Description of adapter card in option slot.
Parameter Numbers
5
Parameter Group
Linear List
Display Units
None
Parameter Type
Read Only
Linkable
No
Selections
0
"No Opt Instd"
[Software Version]
Numeric value of software version.
Parameter Numbers:
1
Parameter Group:
Configuration
Parameter Type:
Read Only
Linkable
No
[Startup State]
Present state value of the startup procedure.
Parameter Numbers
3
Parameter Group
Linear List
Display Units
None
Parameter Type
Read/Write
Change While Running
Yes
Linkable
No
Minimum Value
0
Maximum Value
100
Default Value
1
[State]
Present state of axis module; enabled/disabled.
Parameter Numbers
200, 201, 202, 203
Parameter Group
Linear List
Display Units
None
Parameter Type
Read Only
Linkable
No
Selections
0
"Disabled"
1
"Enabled"
[Status Display]
Textual description of present status of drive.
Parameter Numbers
8
Parameter Group
Linear List
Display Units
None
Parameter Type
Read Only
Linkable
No
Selections
0
"Sys Faulted"
1
"Sys Wait Bus"
2
"Sys Bus Chrg"
3
"Sys Ready"
4
"Sys Enabled"
5
"Sys Stopping"
