Page 283: Two-axis prewired cable

Publication 1394-5.0 — May 2000
Catalog Numbers
D-5
System Module Cables
Control Interface Cables
Single Axis Flying Lead Cable
Two-Axis Prewired Cable
Bulletin
Number
1394
Type
SA15 =
5.9 m (15 ft) cable for the 1394 Servo
AQB interconnect to the motion controller.
GE15 =
5.9 m (15 ft) cable (drive-end connector on one
end and flying leads on the other) from an external
encoder to the 1394 GMC system module. You
will also require 1326-CEU or equivalent cable to
terminate to this cable.
GR04 =
1.2 m (4 ft) cable from the REC (Resolver to
Incremental Encoder Converter) to the 1394
GMC System Module.
FL = Flying Lead
Bulletin
Number
Type
Cable Style and Length
1394
C = Cable
01 = M02AE flying lead to 1394-SJT
xx-A flying lead, 1 axis, 1 m (3.28 ft)
03 = M02AE flying lead to 1394-SJT
xx-A flying lead, 1 axis, 3 m (9.84 ft)
08 = M02AE flying lead to 1394-SJT
xx-A flying lead, 1 axis, 8 m (26.24 ft)
15 = M02AE flying lead to 1394-SJT
xx-A flying lead, 1 axis, 15 m (49.2 ft)
Flying Lead
AE = Analog/Encoder ControlLogix Servo Module
1394 Interface to
AE = Analog/Encoder ControlLogix Servo Module
Bulletin
Number
Type
Cable Style and Length
1394
CC = Cable with ControlLogix
M02AE Connector
01 = M02AE pre-wired connector to 1394
x-SJTxx-A flying lead, 2 axes, 1 m (3.28 ft)
03 = M02AE pre-wired connector to 1394
x-SJTxx-A flying lead, 2 axes, 3 m (9.84 ft)
08 = M02AE pre-wired connector to 1394
x-SJTxx-A flying lead, 2 axes, 8 m (26.24 ft)
15 = M02AE pre-wired connector to 1394
x-SJTxx-A flying lead, 2 axes, 15 m (49.2 ft)
1394 Interface to
