Publication 1394-5.0 — May 2000
Interconnect and CE Diagrams B-7
AXIS MODULE (TYPICAL)
1326A x AC SERVO MOTOR
A
B
D
E
H
G
THERMOSTAT
PE2 PE3 W1 V1
BRAKE
8 7 6 5 4 3 2 1 9
GND
T3 T2 T1 B2 B1 K2 K1
TB1 TB2
U1
MOTOR POWER CABLE
NOTE 4
1 2 3 4 1 2 3 4
PE1
See Thermal Diagrams
for Connections
3.3 mm 2 (12 AWG)
DS1
SOLID GREEN = BUS UP, AXIS ENABLED
FLASHING GREEN = BUS UP, AXIS NOT ENABLED
FLASHING RED/GREEN = READY, BUS NOT UP
FLASHING RED = FAULT
SOLID RED = HARDWARE FAILURE
MOTOR
POWER
MOTOR
RESOLVER
SEE BOTTOM VIEW
FOR RESOLVER CONNECTIONS
DC BUS POS.
DC BUS NEG.
SLIDER INTERCONNECT
CONTROL POWER
& SIGNALS
TERMINATOR CONNECTS
TO THE AXIS MODULE
THERMOSTAT AND BRAKE FEEDTHRU
NOTE 29
MOTOR BRAKE
FILTER (Series C)
MOTOR THERMAL
SWITCH FILTER
(Series C)
TO
SYSTEM MODULE
GROUND BAR
A
