Publication 1394-5.0 — May 2000
Interconnect and CE Diagrams
B-25
1326-CPC1-xxx Standard Power Cable for the 1326AS-B6xxxx,
1326AS-B8xxxx and 1326AB-B7xxxx Servo Motors
1326-CPB1T-xxx Flex Rated Power Cable for 1326AS-B3xxxx,
1326AS-B4xxxx, and 1326AB-B5xxxx Servo Motors
1326-CPC1T-xxx Flex Rated Power Cable for the 1326AS-
B6xxxx, 1326AS-B8xxxx, and 1326AB-B7xxxx Servo Motors
Wire Number
Wire Color
Gauge
mm
2
(AWG)
Connector
Pin
1394
Terminal
1 (Power)
Black
5.3 (10)
1
U1
2 (Power)
Black
5.3 (10)
2
V1
3 (Power)
Black
5.3 (10)
3
W1
4 (Brake)
Black
1.3 (16)
4
TB1-3
5 (Thermostat)
Black
1.3 (16)
5
TB1-2
6 (Brake)
Black
1.3 (16)
6
TB1-4
Braided shield
Braided shield
N/A
7
PE3
(GND)
Green/Yellow
3.3 (12)
8
PE2
9 (Thermostat)
Black
1.3 (16)
9
TB1-1
Wire Number
Wire Color
Gauge
mm
2
(AWG)
Connector
Pin
1394
Terminal
1 (Power)
White
1.3 (16)
1
U1
2 (Power)
White
1.3 (16)
2
V1
3 (Power)
White
1.3 (16)
3
W1
4 (Brake)
White
1.3 (16)
4
TB1-3
5 (Thermostat)
White
1.3 (16)
5
TB1-2
6 (Brake)
White
1.3 (16)
6
TB1-4
Braided Shield
Braided Shield
N/A
7
PE3
(GND)
Green/Yellow
1.3 (16)
8
PE2
9(Thermostat)
White
1.3 (16)
9
TB1-1
Wire Number
Wire Color
Gauge
mm
2
(AWG)
Connector
Pin
1394
Terminal
1 (Power)
White
5.3 (10)
1
U1
2 (Power)
White
5.3 (10)
2
V1
3 (Power)
White
5.3 (10)
3
W1
4 (Brake)
White
1.3 (16)
4
TB1-3
5 (Thermostat)
White
1.3 (16)
5
TB1-2
6 (Brake)
White
1.3 (16)
6
TB1-4
Braided Shield
Braided Shield
N/A
7
PE3
(GND)
Green/Yellow
3.3 (12)
8
PE2
9 (Thermostat)
White
1.3 (16)
9
TB1-1
