6 Configuration
6.2 Digital selector
The digital selector contains all digital signals that are available in the multichannel controller
module for configuration.
The following table lists all digital signals. The entry in the "Type" column indicates the source
of the signal:
•
Internal only: Internal signal that is only available inside the multichannel controller module.
• Internal: Internal signal of the multichannel controller module (including signals of digital in-
puts).
The signal is also transmitted to the base unit via the system bus, to allow it to be used by
other modules.
• External: External input (NV_...) that must be linked in the NV connecting list to a signal
from another module (see Chapter 6.14 "NV connecting list", page 105).
The signal name "NV_..." indicates the intended use; in principle, the signal can also be
used for other purposes.
Category Signal Type Description
Inactive No signal selected
Further signals MasterNotConnected Internal
only No connection to the base unit via
the system bus (controller module
operates independently)
Controller C01ContrLoopMonit to
C04ContrLoopMonit Internal
only Alarm signal of control loop moni-
toring of controller channel 1 to 4
C01OutpLevelMonit to
C04OutpLevelMonit Internal
only Alarm signal of output level moni-
toring of controller channel 1 to 4
C01ManualMode to
C04ManualMode Internal Manual mode active on controller
channel 1 to 4
C01TuneActive to C04TuneActive Internal Self-optimization active for con-
troller channel 1 to 4
C01Output1 to C04Output1 Internal Switch position of first controller
output of controller channel 1 to 4
C01Output2 to C04Output2 Internal Switch position of second control-
ler output of controller channel 1
to 4
C01CollAlarm to C04CollAlarm Internal Collective alarm of controller
channel 1 to 4 (configurable with
signals from the digital selector)
