127

8 Configuration – in setup program only

Function

The math and logic functions are available if the "Math/Logic" option in the setup program has
been activated (Project: Hardware arrangement > Globals).
 Manual for setup program B 705000.6, "Project configuration" section
To make these functions available in the controller module, enable them with the setup program
(CPU: Online parameters > Enabling of extra codes).
 Operating manual for central processing unit B 705001.0, "Online parameters" section

Formula

Use the "Formula Editor" button to open an editor that can be used to create formulae by se-
lecting variables and operators. Formulae can be entered freely according to standard mathe-
matical rules. Any number of spaces may be used within the formula symbol string. Spaces are
not admissible in function designations, names of variables, or constants.

Variable B

Analog selector

Analog signal B (for calculating differen-
tial, ratio, and humidity)

Formula

Display of the formula created with the
formula editor (for math and logic)

Default value

Replacement value for the result of the math function

-99999 to +99999

(or invalid value: -----)

The replacement value is used if the
math function does not produce a valid
result due to an invalid input value.

An invalid value is specified by default
(display: -----).

Parameter

Selection/settings

Description

?

TIP!
The trigonometric functions (SIN, COS, and TAN operators) use degrees (360).

CAUTION!
The processing time for math formulae depends on the quantity, their complexity, and the op-
erators used.
In the least favorable case – and if the controller module is at full capacity at the same time
– this may affect the sampling rate of the controller module inputs (extension of sampling in-
terval).
However, this only affects the sampling rate T50ms (sampling interval 50 ms); the other sam-
pling rates are not affected by this. See Chapter 6.4 "Device data", page 54.
