1 Introduction

14

Fabrication no. (F-Nr)

Among other things, the fabrication number contains the date of production (year/week).
Example: F-Nr = 0070033801211010006
The figures concerned are in positions 12, 13, 14, and 15 (from the left).
The device was therefore produced in the 1st calendar week of 2011.

Identifying the optional modules

The device type (Typ) also contains information about factory-fitted optional modules (in the
example above – 705010/18-113-36 – this is string 113). The optional modules can be identi-
fied by the order details.
This chapter contains additional information to identify optional modules:
Chapter 10 "Retrofitting inputs/outputs", page 137

TIP!
The information on the nameplates must also be considered when replacing the module insert
(Chapter 3.3 "Replacing module inserts", page 24).
