344 Appendix C Setting Up a Control Surface
 R1: Reset Shadow contrast slider
 B1: Reset Shadow color control
 Left joyball: Shadow color control adjustment
 Left wheel: Shadow contrast slider adjustment (black point)
 R2: Reset Midtone contrast slider
 B2: Reset Midtone color control
 Center joyball: Midtone color control adjustment
 Center wheel: Midtone contrast slider adjustment (gamma)
 R3: Reset HIghlight contrast slider
 B3: Reset Highlight color control
 Right joyball: HIghlight color control adjustment
 Right wheel: HIghlight contrast slider adjustment (white point)
Tangent Devices CP100 Control Surface
The Tangent Devices CP100 is a single, large control surface that combines all available
functionality into a single device.
Configuring the CP100 Control Surface
The following procedures describe how to configure and use this control surface with
Color.
Note: You must be logged in as an administrator to set up the Tangent Devices CP100.
To set up and use the CP100 for use with Color:
1 Connect the CP100 to your computer using an Ethernet cable.
Important: The CP100 cannot be connected to the second Ethernet port of your Mac
pro; it must be connected to your computer’s primary Ethernet port, if necessary
through a router or switch if you need to share the port with an Internet connection.
2 Turn on the CP100 and wait for the unit to power up.
3 Open Color.
