To reset any scope to its original scale and orientation:
m Control-click or right-click within any scope, and choose Reset from the shortcut menu.
Some scopes have the option to be displayed in color.
To toggle video scope color on and off:
1 Open the User Preferences tab, located inside the Setup room.
2 Click Monochrome Scopes to turn scope color off or on.
Scope color is affected by the following customizable parameters:
 When Monochrome Scopes is turned off, the UI Saturation parameter determines
how intense the scope colors are.
 When Monochrome Scopes is turned on, the Scope Color control directly underneath
controls the color of the scope graticules.
Analyzing Images Using the Video Scopes
The following section describes the use of each scope that Color provides.
Waveform
The Waveform scope is actually a whole family of scopes that show different analyses
of luma and chroma using waveforms.
What Is a Waveform?
To create a waveform, Color analyzes lines of an image from left to right, with the
resulting values plotted vertically on the waveform graticule relative to the scale that’s
used (for example, –20 to 110 IRE on the Luma graph). In the following image, a single
line of the image is analyzed and plotted in this way.
