Overview

22

NOTE: Figure 3

displays the Director 2/64 Hardware view and

Figure 4

displays the Director

2/140 Hardware view. Other views may display, depending on what you displayed last before

closing the Element Manager.

Figure 3

Director 2/64 Element Manager window

1

Menu Bar

2

View tabs

3

View panel

4

Status bar

2

1

3

4
