Director Element Manager user guide 111

• Click Copy to copy a stored configuration. When the Copy Address Configuration dialog

box displays, provide a name and description for the configuration.

• Names must be between 1 and 8 characters in length. Valid characters are uppercase A–Z,

0–9, hyphen (-), and underscore (_). The name may not be CON, AUX, COMn (where

n=1-9), LPTn (where n=1-9), NUL, or PRN. Descriptions must be between 0 and 24

characters in length. Up to 24 alphanumeric characters are allowed, including spaces,

hyphens, and underscores. Click OK and the configuration is added to the library.

• Click Activate to activate a stored configuration and send it to the switch for immediate use.

A warning displays before the action occurs.

NOTE:

If Active=Saved is enabled through the Configure FICON Management Server

dialog box, this overwrites the current IPL address configuration.

3.

Click Close to close the dialog box when you are finished managing the library.

Configuring an SNMP agent

Use the procedures in this section to:

Configure the SNMP agent that runs on the director and implements the following MIBs:
• MIB-II
• Fibre Channel Fabric Element MIB
• Director private MIB
• Fibre Alliance MIB

NOTE:

For complete information on objects defined in MIBs and steps to download MIB variables

to your SNMP workstation, refer to the HP StorageWorks SNMP reference guide for Directors and

Edge Switches.

Configure network addresses and community names for up to six SNMP trap recipients. An

SNMP trap recipient is a network management station that receives messages through SNMP

for specific events that occur on the director.

Define SNMP community names that SNMP managers use for reading variables.

Authorize write permissions for writable MIB variables.

NOTE:

SNMP managers may request, but will not receive, traps and SNMP data through SNMP

management stations that are not configured with community names.
