Director Element Manager user guide 145

Backup procedure

Use the following procedure to backup your product configuration:

1.

Select Backup and Restore Configuration from the Maintenance menu on the menu bar. The

Backup and Restore Configuration dialog box appears, as shown in

Figure 67

.

Figure 67

Backup and Restore Configuration dialog box

The Backup and Restore Configuration dialog box consists of a short description of the features

performed when you select Backup or Restore.

2.

Click Backup to save the current director configuration to the HAFM appliance. The following is

a list of configurations that are backed up to the HAFM appliance:
• Identification data (director name, description, and location).
• Port configuration data (port names, blocked states, and extended distance settings).
• Operating parameters [BB_Credit, E_D_TOV, R_A_TOV, director priority, preferred domain

ID, rerouting delay, domain RSCNs, and director speed (Director 2/64 only)].

• SNMP configuration (trap recipients, community names, and write authorizations).
• Zoning configuration (active zone set and default zone state).
A backup is immediately attempted when you click Backup on this dialog box. A dialog box

appears to confirm that the backup to the HAFM appliance is complete. If the backup fails, a

dialog box appears to inform you that the backup to the HAFM appliance failed.

Restore procedure

Use the following procedure to restore your product configuration:

1.

Set the director to offline before performing the restore function. If you click Restore and the

director is online, a message dialog appears requesting that you turn the director offline. No

action takes place when you close the dialog box. For instructions on setting the director offline

or online, see ”

Set online state

” on page 142.

2.

Click Restore on the Backup and Restore Configuration dialog box to copy the backed up

configuration to the nonvolatile random access memory (NV-RAM) on the director.
If the director is already offline and you click Restore, a confirmation dialog box appears

indicating that the restore will overwrite any existing configurations already on the director and

it displays the date of the restored backup.

NOTE:

The restore operation initiates an IPL.

The Export Configuration Report function accessed through the Configure menu on the menu

bar is an ASCII file of the backup performed in this section.
