Using maintenance features

146

Reset configuration

This feature is used to reset all configuration data for the director to factory default values. You must

have maintenance authorization rights to access this feature.
The Internet protocol (IP) address will reset to the factory default value during this procedure. You

may not recover the Ethernet connection between the director and HAFM appliance if you have

changed the director’s IP addressing from that default value. In this case you must reenter LAN

addressing, such as IP and gateway addresses, through a terminal attached to the maintenance

port.
Before using the reset configuration option, record the director’s current IP address, which displays

below the icon in the HAFM application’s Product View when the view’s Display Options are set to

Network Address. You can also find the current IP address through the Embedded Web Server

interface.
After resetting the configuration, reset LAN addressing to the desired values through the

maintenance port or the Embedded Web Server interface.
If you have enabled the Full Volatility feature through the director’s maintenance port, this feature

will disable when the configuration is reset.

NOTE:

Use of the maintenance port is not covered in this manual. For procedures, refer to the HP

StorageWorks Director 2/64 service manual for the Director 2/64 and the HP StorageWorks

Director 2/140 service manual for the Director 2/140.

Use the following steps to reset the configuration parameters on the director to the default values.

1.

Select Reset Configuration from the Maintenance menu. The following warning appears:

WARNING!

This operation will reset all director configuration data and nonvolatile

settings to factory default values. The director must be offline to continue.

2.

Set the director offline. For instructions, see ”

Set online state

” on page 142.

3.

To continue the reset operation, click Reset on the Reset Configuration dialog box. If you want

to cancel the operation, click Cancel.

NOTE:

If you have enabled features that add additional port function since the director

was shipped from the factory, these features will be disabled (factory default) when the

configuration is reset. Only those ports that were enabled at the factory will function. You

will have to enable the additional port function features again through the Configure Feature

Key dialog box.
