Configuring the director 114
2. Click New to add a new feature key. The New Feature Key dialog box displays, as shown in
Figure 44 .
Figure 44 New Feature Key dialog box
3. Enter the director’s feature key in the Key field and click OK.
• Feature keys are only valid for a director with a specific serial number. They cannot be
interchanged between directors. If an error stating
Invalid serial number
displays,
verify that you have entered the feature key that was assigned to the director. To verify,
check the serial number of the director through the Switch Properties dialog box and
compare it to the serial number listed in the documentation provided with your feature key.
• The feature key is a string of alphanumeric characters with dashes. The key is case-sensitive,
so enter the key exactly as printed in the documentation that you received for the feature. If
an error stating
Invalid feature key
displays, verify that you have entered the feature
key correctly.
The Enable Feature Key dialog box displays as shown in Figure 45 with a warning, stating that
this action will override the current set of features on the director. The list in the left column of
the dialog box is a list of features that are active on the director. The list on the right is a set of
features that come with the new feature key. All of the features that are active are included in
the new feature list.
Figure 45 Enable Feature Key dialog box
4. Click Activate to activate the new feature key.
An IPL will occur, during which the Ethernet connection between the HAFM appliance and
director is momentarily interrupted.
NOTE: If you click Activate, all current features will be replaced with new features. That is,
if there are features shown in the current list that are not shown in the new list, then those
features will be removed from the director.
