Watlow EZ-ZONE

®

PM Integrated Controller

96

Chapter 6 Setup Page

Setup Page

Dis-

play

Parameter Name

Description

Range

Default

Modbus Rela-

tive

Address

CIP

Class

Instance

Attribute

hex (dec)

Pro-

fibus

Index

Param-

eter ID

Data

Type

&

Read/

Write

[AC;LF]
[AC.LF]

Global

AC Line Frequency

Set the frequency to the

applied ac line power

source.

[``50]

50 Hz (3)

[``60]

60 Hz (4)

60 Hz

Instance 1

Map 1 Map 2

886

1006

0x6A (106)

1

4

89

1034

uint

RWES

[R;typ]

[R.tyP]

Global

Ramping Type

[rate]

Rate (81)

[``ti]

Time (143)

Time

Instance 1

Map 1 Map 2

- - - -

4414

0x7A (122)

1

26 (38)

- - - -

22038 uint

RWE

[P;typ]

[P.tyP]

Global

Profile Type

Set the profile startup to

be based on a set point or

a process value.

[StPt]

Set Point (85)

[`Pro]

Process (75)

Set Point Instance 1

Map 1 Map 2

2534

4354

0x7A (122)

1

8

- - - -

22008 uint

RWE

[`GSE]

[ gSE]

Global

Guaranteed Soak En-

able

Enables the guaranteed

soak deviation function

in profiles.

[`oFF]

Off (62)

[``on]

On (63)

Off

Instance 1

Map 1 Map 2

2530

4350

0x7A (122)

1

6

- - - -

22006 uint

RWE

[GSd1]

[gSd1]

Global

Guaranteed Soak De-

viation 1

Set the value of the de-

viation band that will be

used in all profile step

types. The process value

must enter the deviation

band before the step can

proceed.

0.0 to 9,999.000°F or units

0.0 to 5,555.000°C

10.0°F or

units

6.0°C

Instance 1

Map 1 Map 2

2532

4352

0x7A (122)

1

7

- - - -

22007 float

RWE

[GSd2]

[gSd2]

Global

Guaranteed Soak De-

viation 2

Set the value of the de-

viation band that will be

used in all profile step

types. The process value

must enter the deviation

band before the step can

proceed.

0.0 to 9,999.000°F or units

0.0 to 5,555.000°C

10.0°F or

units

6.0°C

Instance 1

Map 1 Map 2

- - - -

4420

0x7A (122)

1

0x29 (41)

- - - -

22041 float

RWE

[`Si;a]
[ Si.a]

Global

Source Instance A

Set the digital source

for Wait for Event 1 in

profile.

5 to 12

5

Instance 1

Map 1 Map 2

- - - -

4390

0x7A (122)

1

0x1A (26)

- - - -

22060 uint

RWES

[`Si;B]
[ Si.b]

Global

Source Instance B

Set the digital source

for Wait for Event 2 in

profile.

5 to 12

5

Instance 1

Map 1 Map 2

- - - -

4392

7A (122)

1

0x1B (27)

- - - -

22061 uint

RWES

Note:
Some values will be rounded off to fit in the four-character display. Full values can be read
with other interfaces.

R: Read

W: Write

E:

EEPROM

S:

User

Set
