Watlow EZ-ZONE ® PM Integrated Controller • 106 • Chapter 7 Profiling Page
Profiling Parameters
[``p1]]
[prof]
Profile (1 to 4)
[```1]
[``P1] Profile [1 to 4] Step (1 to 40)
[s;typ] Step Type
[t;SP1] Target Set Point Loop 1
[t;SP2]
Target Set Point Loop 2
[hoUr] Hours
[Min] Minutes
[`SEC] Seconds
[rate] Rate
[w;pi]
Wait For Process Instance
[W;P1] Wait For Process 1
[w;E1] Wait For Event 1
[WE;2] Wait for Event 2
[dow] Day of Week
[``js] Jump Step
[``jC] Jump Count
[`EnD] End Type
[Ent1] Event 1
[Ent2] Event 2
Ending a Profile from the Operations Page
1. Navigate to the Operations Page and then the Profile Status menu. From the Home Page, press and hold
the ¿ or Down ¯ key for approximately three seconds where the upper display will show [``ai] and the
lower display will show [oper].
2. Press the Up ¿ or Down ¯ key to navigate to the Profile Status [p ;sta] menu.
3. Press the Advance Key
‰ to enter this menu. The upper display will show [```1] and the lower display
will show [p ;str].
4. Press the Advance Key ‰ to select the Profile Action Request. The upper display will show [none] and
the lower display will show [p ;aCr].
6. Press the Up ¿ or Down ¯ keys to select the End. The upper display will show [`end] and the lower
display will show [p ;aCr].
7. Press the Advance Key ‰ to end the Profile.
8. Return to the Home Page by pressing and holding the Infinity Key ˆ for approximately three seconds.
Starting a Profile from the Home Page
1. When at the Home Page, press the Advance Key ‰ to locate Profile Start and select the file or step num-
ber to start. The upper display will show [```1] and the lower display will show [p ;st1].
2. Press the Up ¿ or Down ¯ key to choose the file or step number.
3. Press the Advance Key ‰ to select the Profile Action Request. The upper display will show [none] and
the lower display will show [p ;aC1].
4. Press the Up ¿ or Down ¯ keys to select the Profile Start. The upper display will show [Prof] and the
lower display will show [p ;aC1].
5. Press the Infinity Key to return Home. The Profile will Start
Ending a Profile from the Home Page
1. Press the Advance Key ‰ to select the Profile Action Request. The upper display will show [none] and
the lower display will show [p ;aC1].
2. Press the Up ¿ or Down ¯ keys to select the End. The upper display will show [~End] and the lower
display will show [p ;aC1]
3. Press the Infinity Key to return Home. The Profile will End.
