Watlow EZ-ZONE

®

PM Integrated Controller

110

Chapter 7 Profiling Page

Profiling Page

Dis-

play

Parameter Name

Description

Range

Default

Modbus

Relative Ad-

dress

CIP

Class

Instance

Attribute

hex (dec)

Param-

eter ID

Data

Type

&

Read/

Write

Ent1]
[Ent1]

Step Type Parameters

Event 1

When Step Type is not Unused

Step, select whether Event

Output 1 or 2 is on or off during

this step.

[`oFF]

Off (62)

[``on]

On (63)

Off

Instance 1

Map 1

Map 2

2582

4512

Offset to next

instance (Map

1 equals +50,

Map 2 equals

+100)

0x79 (121)

1 to 40

7

21007 uint

RWE

[Ent2]
[Ent2]

Step Type Parameters

Event 2

When Step Type is not Unused

Step, select whether Event

Output 1 or 2 is on or off during

this step.

[`oFF]

Off (62)

[``on]

On (63)

Off

Instance 1

Map 1

Map 2

2584

4514

Offset to next

instance (Map

1 equals +50,

Map 2 equals

+100)

0x79 (121)

1 to 40

8

21008 uint

RWE

Note:
Some values will be rounded off to fit in the four-character display. Full values can be read with other
interfaces.

R: Read

W: Write

E:

EEPROM

S:

User Set
