Watlow EZ-ZONE

®

PM Integrated Controller

63

Chapter 5 Operations Page

Operations Page

Dis-

play

Parameter name

Description

Range

Default

Modbus

Relative Ad-

dress

CIP

Class

Instance

Attribute

hex (dec)

Profibus

Index

Param-

eter ID

Data

Type

& Read/

Write

[`C;Lo]
[ C.Lo]

Current (1)

Current Low Set Point

Set the current value

that will trigger a low

heater error state.

-1,999.000 to 9,999.000

0.0

Instance 1

Map 1 Map 2

1136 1376

0x73 (115)

1

9

- - - -

15009

float

RWES

[`CU;r]

[ CU.r]

RMS Current (1)

Current Read

View the RMS current

value monitored by the

current transformer.

0 to 9,999.00

- - - -

Instance 1

Map 1 Map 2

1132 1372

0x73 (115)

1

7

- - - -

15007

float

R

[`C;Er]
[ C.Er]

Current (1)

Current Error

View the most recent

load status.

[nonE]

None (61)

[Shrt]

Shorted (127)

[open]

Open (65)

None

Instance 1

Map 1 Map 2

1160 1400

0x73 (115)

1

2

- - - -

15002

uint

R

[`h;Er]
[ h.Er]

Current (1)

Heater Error

Determine if load cur-

rent flow is within

the High and Low Set

Points.

[nonE]

None (61)

[high]

High (37)

[Low]

Low (53)

None

Instance 1

Map 1 Map 2

1124 1364

0x73 (115)

1

3

- - - -

15003

uint

R

No

Dis-

play

Current (1)

Error Status

View the cause of the

most recent load fault

[nonE]

None (61)

[fail]

Fail (32)

- - - -

Instance 1

Map 1 Map 2

1160 1400

0x73 (115)

1

21

- - - -

15021

uint

R

[MAt]
[oPEr]
Math Menu

[`Su;A]
[ Sv.A]

Math (1)

Source Value A

View the value of Source

A or Linearization 1.

-1,999.000 to 9,999.000°F

or units

-1,128.000 to 5,537.000°C

0.0

Instance 1

Map 1 Map 2

- - - -

3030

0x7D

(125)

1

0x10 (16)

- - - -

25016

float

RWES

[`Su;b]
[ Sv.b]

Math (1)

Source Value B

View the value of Source

B or Linearization 2.

-1,999.000 to 9,999.000°F

or units

-1,128.000 to 5,537.000°C

0.0

Instance 1

Map 1 Map 2

- - - -

3032

0x7D

(125)

1

0x11 (17)

- - - -

25017

float

RWES

[`Su;E]
[ Su.E]

Math (1)

Source Value E

Disables Process/Devia-

tion scale when on.

[`off]

Off (62)

[``on]

On (63)

0

Instance 1

Map 1 Map 2

- - - -

3038

0x7D

(125)

1

0x14 (20)

- - - -

25020

uint

RWES

[oFSt]
[oFSt]

Math (1)

Offset

Set an offset to be ap-

plied to this function's

output.

-1,999.000 to 9,999.000°F

or units

-1,128.000 to 5,537.000°C

0.0

Instance 1

Map 1 Map 2

- - - -

3044

0x7D

(125)

1

0x17 (23)

- - - -

25023

float

RWES

[``o;u]
[ o.v]

Math (1)

Output Value

View the value of this

function's output.

-1,999.000 to 9,999.000°F

or units

-1,128.000 to 5,537.000°C

0.0

Instance 1

Map 1 Map 2

- - - -

3042

0x7D

(125)

1

0x16 (22)

- - - -

25022

float

RWES

Note:
Some values will be rounded off to fit in the four-character display. Full values can
be read with other interfaces.

R: Read

W: Write

E: EEPROM

S: User

Set
