Watlow EZ-ZONE

®

PM Integrated Controller

101

Chapter 6 Setup Page

Setup Page

Dis-

play

Parameter Name

Description

Range

Default

Modbus Rela-

tive

Address

CIP

Class

Instance

Attribute

hex (dec)

Pro-

fibus

Index

Param-

eter ID

Data

Type

&

Read/

Write

[iP;S6]
[ip.S6]

Communications (2)

IP Fixed Subnet Part 6

Set the IP subnet mask

for this module.

0 to 255

0

- - - -

- - - -

- - - -

17025

- - - -

[iP;g1]
[ip.g1]

Communications (2)

Fixed IP Gateway Part

1

Used for the purpose of

sending and receiving

messages from another

network.

0 to 255

0

- - - -

- - - -

- - - -

17026

- - - -

[iP;g2
[ip.g2]

Communications (2)

Fixed IP Gateway Part

2

Used for the purpose of

sending and receiving

messages from another

network.

0 to 255

0

- - - -

- - - -

- - - -

17027

- - - -

[iP;g3]
[ip.g3]

Communications (2)

Fixed IP Gateway Part

3

Used for the purpose of

sending and receiving

messages from another

network.

0 to 255

0

- - - -

- - - -

- - - -

17028

- - - -

[iP;g4]
[ip.g4]

Communications (2)

Fixed IP Gateway Part

4

Used for the purpose of

sending and receiving

messages from another

network.

0 to 255

0

- - - -

- - - -

- - - -

17029

- - - -

[iP;g5]
[ip.g5]

Communications (2)

Fixed IP Gateway Part

5

Used for the purpose of

sending and receiving

messages from another

network.

0 to 255

0

- - - -

- - - -

- - - -

17030

- - - -

[iP;g6]
[ip.g6]

Communications (2)

Fixed IP Gateway Part

6

Used for the purpose of

sending and receiving

messages from another

network.

0 to 255

0

- - - -

- - - -

- - - -

17031

- - - -

[Mb;E]
[Mb.E]

Communications (2)

Modbus TCP Enable

Activate Modbus TCP.

[`YES}

Yes (106)

[``no]

No (59)

Yes

- - - -

- - - -

- - - -

17041

- - - -

[EiP;E]
[EiP.E]

Communications (2)

EtherNet/IP™ Enable

Activate Ethernet/IP™.

[`YES}

Yes (106)

[``no]

No (59)

Yes

- - - -

- - - -

- - - -

17042

- - - -

[ao;nb]
[Ao.nb]

Communications (2)

CIP Implicit Assembly

Output Member Quan-

tity

1 to 20

20

- - - -

- - - -

- - - -

24009

- - - -

Note:
Some values will be rounded off to fit in the four-character display. Full values can be read
with other interfaces.

R: Read

W: Write

E:

EEPROM

S:

User

Set
