Watlow EZ-ZONE

®

PM Integrated Controller

76

Chapter 6 Setup Page

Setup Page

Dis-

play

Parameter Name

Description

Range

Default

Modbus Rela-

tive

Address

CIP

Class

Instance

Attribute

hex (dec)

Pro-

fibus

Index

Param-

eter ID

Data

Type

&

Read/

Write

[`o;Lo]
[ o.Lo]

Digital Output (5 to 12)

Output Low Power

Scale

The power output will

never be less than the

value specified and will

represent the value at

which output scaling

begins.

0.0 to 100.0

0.0

Instance 5

Map 1 Map 2

1016

1136

Offset to next

instance (Map

1 & Map 2)

equals +30

0x6A (106)

5 to C (12)

9

87

6009

float

RWES

[`o;hi]
[ o.hi]

Digital Output (5 to 12)

Output High Power

Scale

The power output will

never be greater than

the value specified and

will represent the value

at which output scaling

stops.

0.0 to 100.0

100.0

Instance 5

Map 1 Map 2

1018 1138

Offset to next

instance (Map

1 & Map 2)

equals +30

0x6A (106)

5 to C (12)

0xA (10)

88

6010

float

RWES

[`leu]
[ LEv]

Digital Input (5 to 6)

Active Level

Select which action will

be interpreted as a true

state.

[high]

High (37)

[LoW]

Low (53)

High

Instance 5

Map 1 Map 2

1320

1560

Offset to next

instance (Map

1 & Map 2)

equals +20

0x6E (110)

5 to 6

1

137

10001 uint

RW

[`leu]
[ LEv]

Digital Input (7 to 12)

Active Level

Select which action will

be interpreted as a true

state.

Note:

Modbus Map 1 has in-

stances 7 and 8 only

[high]

High (37)

[LoW]

Low (53)

High

Instance 7

Map 1 Map 2

1400 1640

Offset to next

instance Map 2

equals +20

0x6E (110)

7 to C (12)

1

137

10001 uint

RW

Note:
Some values will be rounded off to fit in the four-character display. Full values can be read
with other interfaces.

R: Read

W: Write

E:

EEPROM

S:

User

Set
