Watlow EZ-ZONE ® PM Integrated Controller • 102 • Chapter 6 Setup Page
Setup Page
Dis-
play
Parameter Name
Description
Range Default
Modbus Rela-
tive
Address
CIP
Class
Instance
Attribute
hex (dec)
Pro-
fibus
Index
Param-
eter ID
Data
Type
&
Read/
Write
[ai;nb]
[Ai.nb] Communications (2)
CIP Implicit Assembly
Input Member Quan-
tity
1 to 20 20 - - - - - - - - - - - - 24010 - - - -
[`C_F]
[ C_F] Communications (2)
Display Units
Select which scale to use
for temperature passed
over communications
port 2.
[```F] °F (30)
[```C] °C (15)
°F Instance 2
Map 1 Map 2
- - - - 2990
0x96 (150)
2
6
199 17050 uint
RWE
[Map]
[ Map] Communications (2)
Data Map
If set to 1 the control will
use PM legacy mapping.
If set to 2 the control
will use new mapping to
accommodate new func-
tions.
1 to 2 1 if 9 th
digit
of part
number
is a D or
1 other-
wise, 2.
- - - - - - - - - - - - 17059 - - - -
[`nU;S]
[ nU.S] Communications (2)
Non-volatile Save
If set to Yes all values
written to the control
will be saved in EE-
PROM. The EEPROM
allows for approximately
one million writes.
[`yes] Yes (106)
[``no] No (59)
No Instance 2
Map 1 Map 2
2514 2994
96 (150)
2
8
198 17051 uint
RWE
[rtC]
[`SEt]
Real Time Clock Menu
[hoUr]
[hoUr] Real Time Clock
Hours
Set the current time.
0 to 23 0 Instance 1
Map 1 Map 2
- - - - 4004
88 (136)
1
3
- - - - 36003 uint
RW
[Min]
[Min] Real Time Clock
Minutes
Set the current time.
0 to 59 0 Instance 1
Map 1 Map 2
- - - - 4006
88 (136)
1
4
- - - - 36004 uint
RW
[dow]
[doW] Real Time Clock
Day of Week
Set the current day of
the week.
[`sun] Sunday (1565)
[mon] Monday (1559)
[`tue] Tuesday (1560)
[wed] Wednesday (1561)
[thUr] Thursday (1562)
[`fri] Friday (1563)
[`sat] Saturday (1564)
Sun Instance 1
Map 1 Map 2
- - - - 4002
88 (136)
1
2
- - - - 36002 uint
RW
Note:
Some values will be rounded off to fit in the four-character display. Full values can be read
with other interfaces. R: Read
W: Write
E: EEPROM
S: User
Set
